Specifications
| Constant voltage/ current source (VIC/P) |
Number of channels | 4 ch/ board |
|---|---|---|
| Output range | ±18 V/ ±30 mA | |
| Resolution | 16 bits | |
| Voltage range | 2/ 8/ 18 V | |
| Current range | 0.03/ 0.3/ 3/ 30 mA | |
| Matrix | Number of pins | 128 pins/ board |
| Numbers of DUTs tested simultaneously*1 |
Standard specifications 4-DUT measurement 1024 pins |
1 DUT × 1024 pins |
| 2 DUTs × 512 pins | ||
| 4 DUTs × 256 pins | ||
|
Customization 8-DUT measurement 2048 pins |
1 DUT × 2048 pins | |
| 2 DUTs × 1024 pins | ||
| 4 DUTs × 512 pins | ||
| 8 DUTs × 256 pins | ||
| Test head*2 | Negotiable | |
| Calibration | Yes | |
| Self-diagnosis*2 | External self-diagnosis box | |
| External I/F | TTL (for handler/ prober) | |
| USB 2.0 | ||
| LAN (10/ 100/ 1000 Base-Tx) | ||
| Standard specifications 4-DUT measurement 1024 pins |
Dimensions | 600 (W) × 700 (H)*3 × 700 (D) |
| Weight | 65 kg and less | |
| Power consumption | 250 VA and less | |
| Power source | 100 V±10 % 50/ 60 Hz | |
*1 Users can have options to choose 1, 2, 4 or 8 DUTs simultaneous measurement.
*2 Test head and the self-diagnosis function are optional.
*3 The height described in dimensions excludes casters (The height will be 70 mm highter with casters.).
The product design and its specificatoins may be modified for improvement without any prior notice.
We deal with the additional software development on request.
